Portable, compact, efficient sewage treatment solutions for small domestic properties, holiday homes, temporary accommodation and small commercial developments.
Designed for single domestic properties, holiday accommodation, site offices, site toilets, workshops, the Portapura is portable, can be installed above or below ground and treats domestic wastewater to a level that is 25 times better than the recommended EN standard.
Available in three sizes - 2, 3 or 5 person units.
Why choose Portapura?
It’s more efficient than other sewage treatment options… And more portable than all of them.
It’s a space-saving solution… Its compact design provides quick and easy installation with minimum visual impact on the surrounding landscape as well as simple and safe access for maintenance and cleaning. Below ground installation can be achieved in approximately 2 hours
It’s cost-effective… The cost of installing and running the Portapura is minimal when compared to larger, commercial systems.
It’s environmentally sensitive… CE approved to BS EN 12566 with an ammonia result that is 25 times better than the recommended EN standard means the Portapura is well within discharge consent requirements. Electrical consumption: 1.8kWh/d – Equivalent to the daily use of a lightbulb
It’s designed specifically for temporary buildings and small domestic properties… Design objectives included performance, running costs, installation, transport and storage, making the Portapura the logical choice for sites where small wastewater treatment is required. Compact, lightweight construction – No heavy plant required. Near silent air compressor – ensures minimal running, maintenance and servicing costs.
Whisspurr™ acoustic vibration reduction (AVR) unit supplied as standard on all Portapura systems.
Portable – Systems can be installed above ground and removed/stored when not in use
Outstanding treatment efficiency – 14:19:0.7mg/ltr (BOD:Suspended solids:Ammonia)
Fire resistance tested in accordance with EN ISO 11925-2:210, tested for structural integrity in accordance with EN ISO 179-1/1eA.
Neck extensions are available for deeper installations.
Operating Principle
Wastewater enters the primary settlement chamber [A] where large solids are removed by settlement and flotation. An accumulation forms at the base of the tank and is removed by desludging
The clarified water is then transferred to the main aeration chamber [B]. Here it is treated to remove dissolved constituents. Aerobic bacteria, supported by diffused air, ensures full treatment is achieved before the effluent and ‘sloughed off’ bacteria flows to the filter chamber [C] for further solids removal.
The final effluent is then discharged to a water course via the final settlement chamber [D].
Portable, compact, efficient sewage treatment solutions for small domestic properties, holiday homes, temporary accommodation and small commercial developments.
Designed for single domestic properties, holiday accommodation, site offices, site toilets, workshops, the Portapura is portable, can be installed above or below ground and treats domestic wastewater to a level that is 25 times better than the recommended EN standard.
Available in three sizes - 2, 3 or 5 person units.
Why choose Portapura?
It’s more efficient than other sewage treatment options… And more portable than all of them.
It’s a space-saving solution… Its compact design provides quick and easy installation with minimum visual impact on the surrounding landscape as well as simple and safe access for maintenance and cleaning. Below ground installation can be achieved in approximately 2 hours
It’s cost-effective… The cost of installing and running the Portapura is minimal when compared to larger, commercial systems.
It’s environmentally sensitive… CE approved to BS EN 12566 with an ammonia result that is 25 times better than the recommended EN standard means the Portapura is well within discharge consent requirements. Electrical consumption: 1.8kWh/d – Equivalent to the daily use of a lightbulb
It’s designed specifically for temporary buildings and small domestic properties… Design objectives included performance, running costs, installation, transport and storage, making the Portapura the logical choice for sites where small wastewater treatment is required. Compact, lightweight construction – No heavy plant required. Near silent air compressor – ensures minimal running, maintenance and servicing costs.
Whisspurr™ acoustic vibration reduction (AVR) unit supplied as standard on all Portapura systems.
Portable – Systems can be installed above ground and removed/stored when not in use
Outstanding treatment efficiency – 14:19:0.7mg/ltr (BOD:Suspended solids:Ammonia)
Fire resistance tested in accordance with EN ISO 11925-2:210, tested for structural integrity in accordance with EN ISO 179-1/1eA.
Neck extensions are available for deeper installations.
Operating Principle
Wastewater enters the primary settlement chamber [A] where large solids are removed by settlement and flotation. An accumulation forms at the base of the tank and is removed by desludging
The clarified water is then transferred to the main aeration chamber [B]. Here it is treated to remove dissolved constituents. Aerobic bacteria, supported by diffused air, ensures full treatment is achieved before the effluent and ‘sloughed off’ bacteria flows to the filter chamber [C] for further solids removal.
The final effluent is then discharged to a water course via the final settlement chamber [D].
